Junextpower Solis solar 12kw 16KW Single Phase 220V EU Voltage Hybrid Solar Inverter Energy Storage MPPT Inverters

Name: Junextpower Solis solar 12kw 16KW Single Phase 220V EU Voltage Hybrid Solar Inverter Energy Storage MPPT Inverters
Brand: JUNEXT
Price: 1 USD

Quality Junextpower Solis solar 12kw 16KW Single Phase 220V EU Voltage Hybrid Solar Inverter Energy Storage MPPT Inverters for sale

Brand Name : JUNEXT

Model Number : JN-E-SUN 6.2KVA/48V

Certification : ISO、UN38.3、CE、MSDS

Place of Origin : shenzhen

MOQ : Low MOQ

Payment Terms : ,T/T

Supply Ability : 200pcs/day

Contact Now

Junextpower Solis solar 12kw 16KW Single Phase 220V EU Voltage Hybrid Solar Inverter Energy Storage MPPT Inverters

Pure sine wave hybrid on-grid/off-grid inverter with grid-tie function

Optional local WiFi & GPRS connectivity, compatible with iOS and Android devices

Supports inverter operation in both battery and battery-free modes

Integrated automatic activation function for lithium batteries

Built-in 120A MPPT solar charge controller

Wide PV input voltage range (90–450VDC)

Dual output channels (L1/L2)

Optional BMS available for 4.2K, 6.2K and 10.2K models, BMS included as an option

User-friendly LCD operation interface

Boosted charging power performance

Product Parameters

New Model	JN-E-SUN 6.2KVA/48V
Max.PV Power	6500W
Rated Power	6200VA
Max.Charge Current	100A
Battery
Battery Voltage	48VDC
Floating Charge Voltage	54VDC
Overcharge Protection	63VDC
Battery Type	Compatible With GEL,AGM,Lithium battery
Grid Input
Voltage	230VAC
Selectable Voltage Range	170-280VAC(For Personal Computers),90-280 VAC (For Home Appliances)
Frequency Range	50 Hz/60 Hz (Auto sensing)
Efficiency(AC Mode)	98%
Ac Output
AC Voltage Regulation(Batt.Mode)	230 VAC 士 5%
Surge Power	12400VA
Efficiency (Peak)	90%-94%
Transfer Time	10 ms(For Personal Computers);20 ms (For Home Appliances)
Waveform	Pure sine mave
Dual Loads Acoutput
Full Load	6200VA
Maximum Main Load	6200VA
Maximum Second Load(Battery Mode)	2100W
Main Load Cut Off Voltage	44VCD
Main Load Retum Voltage	54VCD
Solar Charger&Ac Charger
Solar ChargerType	MPPT
Maximum PV Array Power	6500W
Max. input Current	27A
MPPT Range @ Operating Voltage	90-450VDC
Maximum PV Aray Open Circuit Vollage	500 VDC
Maximum Solar Charge Current	100A
Maximum Ac Charge Curent	100A
Maximum Charge Curent	100A
Physical
Packing Dimension,DWH(mm)	543394204
Net Weight (kg)	10.5
Communication interface	USBIRS232/WIFI/GPRS
Operating Environment
Humidity	5% to 95%6 Relative Humidity(Non-condensing
Operaling Temperature	-10℃ to 50℃
Storage Temperature	-10℃ to 50℃

Junextpower Solis solar 12kw 16KW Single Phase 220V EU Voltage Hybrid Solar Inverter Energy Storage MPPT Inverters
